The RC-21BRFS is an imaging chamber with field stimulation electrodes. A pair of platinum wires is epoxied into the parallel sides of the oval shaped bath. The connecting wires are terminated in 1 mm pins. The chamber uses a pair of 25 mm round coverslips. Bath volume is 260 µl. The additional port at the chamber perfusion input may be used for removing bubbles or injecting a substance. At the bath output, a length of tubing is use as a back pressure control to insure a smooth perfusion flow.

Order with P-2 or PH-2 platform.
