The RC-20 and RC-20H are very small volume imaging chambers featuring fast perfusion exchange and short working distance. Two 15 mm diameter coverslips enclose the bath. Distance between top and bottom coverslips is 1 mm. The top coverslip is held in place with a retainer. The sample coverslip is placed on the chamber bottom and the assembled chamber is placed in the chamber platform.

Two bath sizes are available. The smaller and narrower bath of the RC-20 insures a linear flow and fast solution exchange while the larger RC-20H provides a larger viewing area The additional port at the bath input may be used to inject substances or to remove gas bubbles.

Order with P-5 or PH-5 platform.
