Benefits
True Current Clamp operations
with measured membrane
potential and comlete cancellation of series resistance.
Can
be used with sharp microelectrodes, and patch pipettes
in whole-cell and perforated-patch configuration.
Can
be used for extracellular recording as well.
POTENTIAL
OUTPUT GAIN: 10, 20, 50, 100, 200, 1k
HIGHPASS
filter: DC, 0.1, 0.3, 0.5, 1, 3, 5, 10, 30, 50, 100, 300, 500,
600, 1k, 3k Hz
LOWPASS
filter: 20, 50, 100, 300, 500, 700, 1k, 1.3k, 2k, 3k, 5k, 8k, 10k,
13k, 20k Hz
CURRENT
OUTPUT SENSITIVITY: 0.1, 0.2, 0,5, 1, 2, 5, 10 V/nA
Digital
DISPLAYS for current, voltage and electrode resistance
BUZZ
and ELECTRODE CLEAR facility
OSCILLATION
SHUT-OFF prevent cells from damage
Digital
setting of gated stimulus ampltude, setting and digital read-out
of holding current
Enhanced
(x10) currend range for electroporation or iontophoresis
